SFW-08L

Input voltage: +12VDC RMS Power :200W THD :<0.5% Signal-to-noise ratio : > 95dB Frequency response :25Hz-200Hz Input sensitivity, high level : 5.4V Input sensitivity, low level :280mV Low Pass Filter : 50Hz -200 Hz Bass Boost : 0 to +12dB Subsonic Filter :25Hz Fuse rating : 15A Subwoofer : 9.5inch Dimensions:L345xW245xH85mm

10 INCH SUPER SHALLOW Input voltage: +12VDC RMS Power : 100W THD :<0.3% Signal-to-noise ratio : >90dB Frequency response :30-180Hz Input sensitivity, high level : 1.0V Input sensitivity, low level : 300mV Low Pass Filter :50-180Hz Bass Boost : 0 to +12dB BSubsonic Filter : 30Hz Fuse rating : 20A Subwoofer :10inch,4ohm Dimensions:L345xW245xH70mm

SFW-760T 7.6 INCH SUPER SHALLOW Input voltage: +12VDC RMS Power : 100W THD :<0.3% Signal-to-noise ratio : >90dB Frequency response :30Hz-180Hz Input sensitivity, high level : 1.0V Input sensitivity, low level : 300mV Low Pass Filter : 50Hz-180Hz Bass Boost : 0 to +12dB Subsonic Filter : 30Hz Fuse rating : 20A Subwoofer :7.6inch,4ohm Dimensions: L260xW195xH58mm

SFW-08R Input voltage: +12VDC RMS Power :100W THD :<0.3% Signal-to-noise ratio : >90dB Frequency response :20Hz-180HZ Input sensitivity, high level : 1.0V Input sensitivity, low level : 300mV Low Pass Filter :50Hz-180Hz Bass Boost : 0 to +12dB Subsonic Filter : 20Hz Fuse rating : 15A Subwoofer :6.5inch,4ohm Dimensions:L246xW296xH80mm
